Batco 1844 Electric Belt Conveyor, 44′ Length, 18″ Belt, Up to 10,500 BPH

The Batco FX4-1844FLTD is a 44-foot electric field-loader conveyor with an 18-inch chevron belt and 12.75-inch tube. Batco rates it at up to 10,500 bushels per hour with dry wheat for higher-rate field-loading and transfer work.

The field-loader top drive is located near the discharge end. A collapsible steel hopper feeds the belt, while the hand winch, A-frame undercarriage, parking jack, and transport tires handle routine positioning around the site. At a 23-degree operating angle, the bottom of the discharge spout is approximately 14 feet 11.9 inches above the ground.

Specifications

Specification	Value
Model	FX4-1844FLTD
Conveyor length	44 ft.
Published capacity	Up to 10,500 bu./hr. with dry wheat
Tube	12.75 in. OD x 12 ga.
Belt	18 in. chevron; approximately 94 ft. 1 in. long
Electric power	15 HP with dry wheat
Hopper	Approximately 54.75 x 36.375 x 21.875 in.
Lift and frame	Hand winch; A-frame
Conveyor width	90 in. hub face to hub face
Approximate weight	2,064.5 lb.

The 15 HP drive should be matched to the available voltage, phase, service capacity, disconnect, plug, and cord. Verify the discharge height at the site's actual working angle rather than relying on overall length alone. The published rate is based on dry wheat and will vary with product, moisture, incline, and intake flow.
