Baumalight QC100 PTO Generator, 100 kW, Single-Phase 120/240V, 1000 PTO Only, 400 Amps

The Baumalight QC100 is a 100 kW single-phase PTO generator for 120/240V backup and portable power. It is rated for 300 kW of momentary surge and uses a 1000 RPM tractor PTO.

PTO Generator Design

The QC design uses four oversized copper windings and operates at 1,800 internal RPM. Three speed-indicator lights help the operator bring the generator to the correct operating speed before applying the electrical load.

• 100 kW continuous output
• 300 kW momentary surge rating
• 400-amp full-output main breaker
• Four-pole generator operating at 1,800 internal RPM

QC100 Specifications

QC100 Fitment

Full rated output requires approximately 153 tractor horsepower, while 50 percent load requires approximately 71 horsepower. Confirm the tractor's 1000 RPM PTO, available horsepower, driveline guarding, electrical load, transfer equipment, grounding, and connection plan with qualified electrical personnel.

Compare the QC100's output and PTO requirements with other models in our PTO generators. Browse our Baumalight equipment for additional tractor-powered equipment.

How much tractor power does the QC100 require?

Baumalight specifies approximately 71 horsepower at 50 percent load and 153 horsepower at full load.

What PTO speed does the QC100 use?

The QC100 uses a 1000 RPM PTO.

What voltage and phase does it produce?

The QC100 provides 120/240V single-phase output with a 400-amp main breaker.
