Baumalight QC19 PTO Generator, 19 kW Single Phase, 120/240V, 540 PTO, 90 Amp Main Breaker

Overview

The Baumalight QC19 PTO Generator is a tractor-powered backup and remote power solution built to deliver reliable single-phase 120/240V power anywhere you can bring a tractor. With 19 kW rated output and 540 PTO drive, it’s a strong fit for farms, acreages, and job sites that want dependable power without maintaining a separate engine-driven generator.

Built on a 4-pole generator platform (1,800 RPM internal), the QC19 is designed for steady frequency and smooth power delivery under real-world loads. It includes Baumalight’s DisplayMaster1 monitoring for quick setup and at-a-glance performance, plus a dedicated connection panel and multiple receptacles for flexible use.

Key Features

19 kW Rated Output + 35 kW Momentary Surge
Handles steady running loads with 35 kW momentary surge capacity to help with motor starts and short load spikes.

Single-Phase 120/240V Power (Dedicated Connection)
Supplies standard North American split-phase power for shops, barns, homes, and equipment during outages or remote work.

540 PTO Driven, 4-Pole / 1,800 RPM Internal
Runs from a 540 PTO and uses a 4-pole generator design with 1,800 RPM internal speed for stable output and long-duty operation.

DisplayMaster1 Monitoring
Built-in monitoring simplifies setup and helps you verify voltage, frequency, amperage, kW/kVA, power factor, runtime, and other key readings.

90 Amp Main Breaker Protection
Integrated 90A main breaker provides full-output protection and straightforward load management.

Full Connection Panel with Multiple Outlets
Includes a practical mix of receptacles for common farm and jobsite needs:

• 240V 50A range-style receptacle

• 240V 50A welder-style receptacle

• Four 120V 20A duplex outlets

Technical Specifications
